Designed for both classroom and laboratory environments, the CxL reflects a sleek design composed of a durable aluminum stand, high throughput glass and optical coatings, and brass gears, all of which position the CxL to withstand the most demanding of user environments. And with lead-free optics and paints, the CxL is a truly eco friendly solution.
Advantages of CXL
-
Objective
Finite LP series DIN Semi-Plan Achromatic objectives 4x (NA 0.10/WD 19.0mm), 10x (NA 0.25/WD 6.4mm), 40x (spring/NA 0.65/WD 0.45mm), 100x (spring, immersion oil/NA1.25/WD0.09mm)
-
Nosepiece
Quadruple nosepiece turret (Ball bearing type) with rubber grip
-
Viewing Body
45° inclined, 360° captive rotation Monocular head, WF 10x/18mm eyepiece
-
Electronics
Universal input 100V- 240V AC, 50/60Hz, built-in voltage stabilizer Dimensions (mm) Labomed CxL Microscope Line Drawing
-
Stand
Single mold aluminum die-cast with ergonomic handrests for enhanced comfort and stability.
-
Eyepiece
Widefield 10x/18mm focusable eyepieces with foldable eye guard, lockable, antifungal coating
-
Condenser
Sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with snap-in blue filter. Rack and pinion movements on metal guides
-
Mechanical Stage
Stage 135 x 124mm, with X/Y travel range 76 x 50mm. Low drive movement controls, single specimen holder
-
Focusing
Co-axial coarse and fine focusing on ball drive system for smooth operation. BRASS rack and pinion stage drive. Fine drive movement 0.3mm/rotation
-
Illumination
LED illumination (LiON rechargeable battery) with intensity control, 100V-240V AC universal power supply
- Shipping
Please contact us for current lead times.
| Model | Objectives | Illum | Power | Benz $ | List $ |
| 9135008 | 4/10/40R | Variable LED | Rechargeable Battery | 571 | 635 |
| 9135005 | 4/10/40R/100R | Variable LED | Rechargeable Battery | 594 |
660 |
Accessories (Optional)
- Pointers & Micrometer Reticules
- Phase, Polarizing, and Dark Field Kits
- Auxiliary Objectives and Eyepieces
- Cord Hanger Kit
- Digital Cameras and Adapters
- Soft Carrying Case
