Motic SWIFTLINE M3-F Series Forensic Comparison Microscope, Trinocular
- Sale price
- $2,369 USD
- List price
- $2,494 USD
Motic SWIFTLINE M3-F Series Forensic Comparison Microscope, Trinocular
A truly unique concept in microscopy! The M3-F forensic microscope offers professional features at a highly competitive price point. Use the M3-F's revolutionary technology to compare images in both micro and macro environments. The M3's dedicated macro lens, with a large working distance, allows you to view not only bullets but also larger more bulky, "evidence" items. Swift's powerful optical system allows for images to be seen either 100% from the left microscope, 100% from the right, side-by-side, or overlapping. The M3-F is the first and only comparison microscope at this price level that can achieve overlapping of images. With the included C-mount adapter, you can easily attach any C-mount ready imaging device. Motic Trace, a forensic comparison software program, is also available and sold as an additional application.
Available with optional detachable Android tablet enabling simultaneous viewing of specimen. Look for M3-F-BTI1 (8" Tablet) and M3-F-BTI2 (10" Tablet).
Widefield 10x /18mm eyepieces.
Trinocular viewing head with 45° inclined eyepiece.
DIN standard 4x (0.10 N.A.), 10x (0.25 N.A.), 40xR (0.65 N.A.) achromat objectives, and 1X Macro objective.
Quad objective turret is ball-bearing mounted for smooth, precise positioning of objectives.
USE OF TRINOCULAR PORT
To use the trinocular port with a digital video camera, you must purchase a video C-mount adapter with a 0.5X lens (MA15602).
ILLUMINATION
LED light rated up to 50,000 hours of life.
Batteries allow up to 500 recharges, for a total of 20,000 to 25,000 hours of use. Battery charger included with microscope, automatically shuts off when batteries are fully charged, no danger of overcharging batteries and shortening battery life. No expensive recharger station needed/ Plug directly into wall outlet, or use ordinary, inexpensive power strip for recharging multiple microscopes. Indicator light changes from red to green when fully charged.
ELECTRICAL
110V - 220V switching power supply, unit shipped with American plug.
FOCUSING
Coaxial coarse and fine focusing controls.
STAGE
Circular stage with diameter of 4 in. (97mm).
Gliding stage plate with "one-touch" stage clips.
Stage plate with 0.65 condenser.
Sealed iris diaphragm.
One-touch stage clips.
Black and white stage disks, and specimen cup.
8" or 10" LCD Android tablet with 1280x800 screen resolution
Connection: WiFi; micro SD card
WiFi Resolution 1920x1080 / 1280x720
4.0MP capture resolution
WiFi (2.4 or 5GHz) and Ethernet (RJ45)
MotiConnect App
Connect 5 WiFi devices at one time
Connect office/clinic/business network through RJ45 port connection
CAMERA
1/3" CMOS
4.0MP Capture resolution
1920x1080 / 1280x720 Resolution (RJ45 or WiFi)
5V (External power supply)
2.4 and 5Ghz WiFi - Ethernet (RJ45)
REQUIRED SPECIFICATIONS
Network connection provided through RJ45
Android or iOS ready device
WiFi Adapter (PC and Mac only)
This camera system is designed specifically for Swift, National , and Motic C-Mounts adapters and microscopes. No support is provided for third party adapters or microscopes.
Download the MotiConnect app for free!
FRAME
M3-F includes two microscope bodies.
Ship wt.: 53 lbs.
Ergonomic carry handles, promote proper handling.
Tripod legs allow for sturdy footing
PACKING
Frame and base in molded styrofoam container with vinyl dustcover.
Individual: Ship wt. 53 lbs (24.0 kgs), Dimensions 26x21x16 in. (66x53x41 cm.)
Master carton pack 1 each: Ship wt. 53 lbs (24.0 kgs), Dimensions 26x21x16 in. (66x53x41 cm.)
